Home  >  Motors  >  Refrigeration  >  Watt Motor  > 9 WATT 1/83HP 115V 1550RPM

9 WATT 1/83HP 115V 1550RPM

No. of Poles 4 Motor Type Shaded Pole Enclosure TEAO HP (Max.) 9 Watt Voltage 115 Mounting 1 Boss/PE & OPE 3 Holes Speeds 1 Hz 60 Rotation CCW SE RPM Range 1550 NEMA Frame Size 3.3 Phase Single Standards UL/CUL FLA 0.58 Bearing Sleeve Lead Length (in.) 22-23 Lead w/Ring Terminal Thermal Protection Yes Ambient Deg C 40 Ins. Class B Shaft Dia. (in.) 1/4 Capacitor Included No Shaft Length (in.) 0.49 Duty Continuous
Item #: 00807
9 WATT 1/83HP 115V

ELCO - Refrigeration Motor

  • 3.3" Diameter
  • One Foot, Front Shroud, 3 Tapped Rear Holes
  • Shaft with 4 End-Studs

Motors

No. of Poles
4
Motor Type
Shaded Pole
Enclosure
TEAO
HP (Max.)
9 Watt
Voltage
115
Mounting
1 Boss/PE & OPE 3 Holes
Speeds
1
Hz
60
Rotation
CCW SE
RPM Range
1550
NEMA Frame Size
3.3
Phase
Single
Standards
UL/CUL
FLA
0.58
Bearing
Sleeve
Lead Length (in.)
22-23 Lead w/Ring Terminal
Thermal Protection
Yes
Ambient Deg C
40
Ins. Class
B
Shaft Dia. (in.)
1/4
Capacitor Included
No
Shaft Length (in.)
0.49
Duty
Continuous
Brand
Morrill Motors
Pack Qty
1
Case Qty
12
Pallet Qty
288
Length
5.40 in.
Width
5.30 in.
Height
5.30 in.
Weight
2.7000 lbs
Harmonized Tariff Code
8501400000
UPC
685744008071
Country of Origin Code
CN
Country of Origin Name
China
