Home  >  Motors  >  HVAC  >  Draft Inducer  > GOODMAN 80% 0131G00007

GOODMAN 80% 0131G00007

Motor Type PSC Enclosure Open H.P. (Max.) 1/50 Voltage 230 Speeds 1 Hz 60 Rotation CCW RPM Range 3000 NEMA Frame Size 2.6"/65mm Phase Single Standards CUL FLA 0.24 Bearing Ball Shaft Length Inches 3.85 Shaft Dia Inches 0.3 Thermal Protection BR-A1D150 Ambient Deg C 60 Ins. Class Class F Capacitor Included Yes Capacitor Rating 2/370V
Item #: 10550
10550

Motors

Motor Type
PSC
Enclosure
Open
H.P. (Max.)
1/50
Voltage
230
Speeds
1
Hz
60
Rotation
CCW
RPM Range
3000
NEMA Frame Size
2.6"/65mm
Phase
Single
Standards
CUL
FLA
0.24
Bearing
Ball
Shaft Length Inches
3.85
Shaft Dia Inches
0.3
Thermal Protection
BR-A1D150
Ambient Deg C
60
Ins. Class
Class F
Capacitor Included
Yes
Capacitor Rating
2/370V
MFG NameMFG #
Goodman0131G00007

Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
