Home  >  Motors  >  ECM  >  Refrigeration  > AZURE 4-25W IP67

AZURE 4-25W IP67

No. of Poles 8 Motor Type ECM Enclosure TEAO HP (Max.) 4-25 Watts Voltage 115/230 Mounting Belly Band, Extended Clampbolts Speeds 1 Hz 60/50 Rotation CWLE Multi-Rated HP 4-25 Watts RPM Range 1550 NEMA Frame Size 51 Phase Single Standards CUL FLA Proprietary Bearing Ball Lead Length (in.) 12 Thermal Protection Auto Ins. Class A Shaft Dia. (in.) 1/4 Capacitor Included No Shaft Length (in.) 0.44 Duty Continuous
Item #: 10891

Azure ECM Commercial Refrigeration

  • Watt Motor - Reach in Cooler
  • No capacitor is required
  • Wirelessly Programmable
  • Free app (AZURE ECM)
  • Submersible - IP67
  • Self adjusting from 4 to 25 Watts
  • Auto Voltage Select (115/230V)
  • 1550 RPM - Default, 600-2000 RPM adjustable
    •

    Motors

    No. of Poles
    8
    Motor Type
    ECM
    Enclosure
    TEAO
    HP (Max.)
    4-25 Watts
    Voltage
    115/230
    Mounting
    Belly Band, Extended Clampbolts
    Speeds
    1
    Hz
    60/50
    Rotation
    CWLE
    Multi-Rated HP
    4-25 Watts
    RPM Range
    1550
    NEMA Frame Size
    51
    Phase
    Single
    Standards
    CUL
    FLA
    Proprietary
    Bearing
    Ball
    Lead Length (in.)
    12
    Thermal Protection
    Auto
    Ins. Class
    A
    Shaft Dia. (in.)
    1/4
    Capacitor Included
    No
    Shaft Length (in.)
    0.44
    Duty
    Continuous
    MFG NameMFG #
    Century/AO Smith9207F2, 9208F2, 9211,9213
    US Motors/EmersonEC5411D,EC5412D
    Hussman4410547
    Morrill5R999
    OtherAll standard watt motors 4 -25W

    Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.
