Home  >  HVAC/R Components  >  Fan Blades  >  2 Fixed Wing  > 18" 2W 29 DEG CW 1/2" H-INT

18" 2W 29 DEG CW 1/2" H-INT

Diameter (in.) 18 Type Fixed Hub No. of Blades 2 Bore Diameter (in.) 1/2 Pitch (Degree) 29 Rotation CW Material Aluminum Max. RPM 1050 Depth (in.) 4 5/8 CFM @ 0.000-In. SP 2399 Min. HP @ 0.000-In. SP 0.0808 CFM @ 0.300-In. SP 2281 Min. HP @ 0.300-In. SP 0.0834
Item #: 40307

Standard Pack: 2
Must order in multiples of: 2
40307

Fixed Hub Fan Blades

  • High strength aluminum alloy
  • Designed for lower static pressure applications
  • Fits many OEM's

Fan Blades

Diameter (in.)
18
Type
Fixed Hub
No. of Blades
2
Bore Diameter (in.)
1/2
Pitch (Degree)
29
Rotation
CW
Material
Aluminum
Max. RPM
1050
Depth (in.)
4 5/8
CFM @ 0.000-In. SP
2399
Min. HP @ 0.000-In. SP
0.0808
CFM @ 0.300-In. SP
2281
Min. HP @ 0.300-In. SP
0.0834
