Home  >  HVAC/R Components  >  Contactors  >  MARS 780 Contactors  > 2P 30A 120V QC & SC TERM

2P 30A 120V QC & SC TERM

Contactor Type Definite Purpose No. of Poles 2 FLA Inductive 30 FLA Resistive 40 Coil Voltage 120 Coil Hz 50/60 Lug or Screw Terminal Screw/Quad QC Standards UL No. of QC Terminals Per Pole 4
Item #: 61346
61346

MARS 780 Professional Grade Definite Purpose Contactors

  • Designed for use on refrigeration, air conditioning and electric heating systems
  • Engineered for today's most demanding commercial refrigeration and HVAC applications
  • Enclosed body provides a quieter running contactor and a longer life expectancy
  • Oversized Arch Window to simplify wiring
  • High Performance Copper & Brass Conductors maximize current carrying capability creating a cooler running contactor
  • Multi-purpose Coil Terminals allow the use of QC terminals or stripped wires
  • Removable Coils allow field replacement of damaged coils
  • Removable Cover provides full access to the contacts
  • Thermoplastic Housing resists dusting and contamination of the contacts to maintain maximum conductivity

Contactors

Contactor Type
Definite Purpose
No. of Poles
2
FLA Inductive
30
FLA Resistive
40
Coil Voltage
120
Coil Hz
50/60
Lug or Screw Terminal
Screw/Quad QC
Standards
UL
No. of QC Terminals Per Pole
4
MFG NameMFG #
Siemens/Furnas45EG20AF, 45CG20AF, 45DG20AF

Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

©MOTORS & ARMATURES, INC.
MFG NameMFG #
A-1 ComponentF30AMP2P120V, 7309
Copeland912203001
Cutler HammerC25BNB230A
HartlandCON-2/120/30, HCC-2XT01AA
HoneywellDP2030B5003, DP2030B1002
IRPDP230120F
PackardC2S30B
Square DDP32VO2, 8910DP22V02
SUPCODP301202
ZettlerXMC0-252FBBC

Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

©MOTORS & ARMATURES, INC.
