Home  >  HVAC/R Components  >  Contactors  >  MARS 780 Contactors  > 3P 50A 120V BOX LUG TERM

3P 50A 120V BOX LUG TERM

Contactor Type Definite Purpose No. of Poles 3 FLA Inductive 50 FLA Resistive 63 Coil Voltage 120 Coil Hz 50/60 Lug or Screw Terminal Box Lug/Dual QC Standards UL No. of QC Terminals Per Pole 2
Item #: 61461
61461

MARS 780 Professional Grade Definite Purpose Contactors

  • Designed for use on refrigeration, air conditioning and electric heating systems
  • Engineered for today's most demanding commercial refrigeration and HVAC applications
  • Enclosed body provides a quieter running contactor and a longer life expectancy
  • Oversized Arch Window to simplify wiring
  • High Performance Copper & Brass Conductors maximize current carrying capability creating a cooler running contactor
  • Multi-purpose Coil Terminals allow the use of QC terminals or stripped wires
  • Removable Coils allow field replacement of damaged coils
  • Removable Cover provides full access to the contacts
  • Thermoplastic Housing resists dusting and contamination of the contacts to maintain maximum conductivity

Contactors

Contactor Type
Definite Purpose
No. of Poles
3
FLA Inductive
50
FLA Resistive
63
Coil Voltage
120
Coil Hz
50/60
Lug or Screw Terminal
Box Lug/Dual QC
Standards
UL
No. of QC Terminals Per Pole
2
MFG NameMFG #
Siemens/Furnas42DF35AF

Be careful! The information provided is intended to serve as a reference to assist in the selection of products sold by MARS. It is the responsibility of users to validate any cross reference information provided to determine suitability for the intended application. The company is using the competitor's brand names for reference only, and without license or permissions of those companies.

©MOTORS & ARMATURES, INC.
MFG NameMFG #
Copeland912305001
Cutler HammerC25FNF350A
DiversitechEC503120
EatonDPE503120
HartlandCON-3/120/50
HoneywellDP3050B5000, DP3050B1009
IRPDP350120F
PackardC3L50B
Packard Titan MaxTMX350B2
Square D8910MO3
Smart ElectricSE3711M
SUPCODP501203
