Home  >  Motors  >  Refrigeration  >  3.3 Inch  > 1/15HP 115/230V 3.3 MCQWAY REP

1/15HP 115/230V 3.3 MCQWAY REP

No. of Poles 4 Motor Type Shaded Pole Enclosure Open HP (Max.) 1/15 Voltage 115/230 Mounting Thru Bolt Speeds 1 Hz 60 Rotation CW RPM Range 1550 NEMA Frame Size 3.3 Phase Single Standards CSA FLA 2.2/1.1 Bearing Sleeve Lead Length (in.) 14 Thermal Protection Auto Ambient Deg C 40 NOTE Voltage Change Ext. Connection Box Ins. Class B Shaft Dia. (in.) 5/16 Capacitor Included No Shaft Length (in.) 2.25 Duty Continuous
Item #: 09934
1/15HP 115/230V 3.3

MARS One-On-One Commercial Refrigeration Evaporator Fan & Blower Motors

  • Sleeve Bearing
  • Original OEM-type mounting
  • Original OEM-type wiring
  • Specially selected low temp oil
  • Full flatted oxide shaft

    • Motors

    No. of Poles
    4
    Motor Type
    Shaded Pole
    Enclosure
    Open
    HP (Max.)
    1/15
    Voltage
    115/230
    Mounting
    Thru Bolt
    Speeds
    1
    Hz
    60
    Rotation
    CW
    RPM Range
    1550
    NEMA Frame Size
    3.3
    Phase
    Single
    Standards
    CSA
    FLA
    2.2/1.1
    Bearing
    Sleeve
    Lead Length (in.)
    14
    Thermal Protection
    Auto
    Ambient Deg C
    40
    NOTE
    Voltage Change Ext. Connection Box
    Ins. Class
    B
    Shaft Dia. (in.)
    5/16
    Capacitor Included
    No
    Shaft Length (in.)
    2.25
    Duty
    Continuous
