Home  >  Comfort-Aire  >  Evaporator Coils  >  Fin & Tube  >  Uncased  > COIL UNCASED A 2-2.5T R-410A

COIL UNCASED A 2-2.5T R-410A

PISTON 14 INCH WIDE CC3
Coil Type Copper Tube/Alum Fin Cased/Uncased Uncased Positioning Vertical Upflow/Downflow Refrigerant R-410A Nom. Capacity (Tons) 2.5 Fits Furnace Width (in.) 14.5 Width (in.) 15 Metering Device Piston/Flowrator Warranty 19.5 Depth (in.) 14 Liquid Line Connection (in.) 3/8 Shipping Wt (lbs) Standard and extended warranty available Height (in.) 28 Suction Line Connection (in.) 3/4 Connection Side Right hand for copper and drain Test Listing UL US and Canada No. Tube Rows 3 NOTE 12 yr. warranty when part of AHRI matched system Certification AHRI 210/240 when part of a matched system
Item #: CCG2430PA3P
CCG2430PA3P

Uncased coils for use with split system A/C and heat pump systems

  • Rifled copper tubing with aluminum fins
  • Factory installed piston
  • Heavy duty corrosion resistant drain pan
  • AHRI matched to our split system condensers and heat pumps

Fin & Tube

Coil Type
Copper Tube/Alum Fin
Cased/Uncased
Uncased
Positioning
Vertical Upflow/Downflow
Refrigerant
R-410A
Nom. Capacity (Tons)
2.5
Fits Furnace Width (in.)
14.5
Width (in.)
15
Metering Device
Piston/Flowrator
Warranty
19.5
Depth (in.)
14
Liquid Line Connection (in.)
3/8
Shipping Wt (lbs)
Standard and extended warranty available
Height (in.)
28
Suction Line Connection (in.)
3/4
Connection Side
Right hand for copper and drain
Test Listing
UL US and Canada
No. Tube Rows
3
NOTE
12 yr. warranty when part of AHRI matched system
Certification
AHRI 210/240 when part of a matched system
