Home
>
Century
>
Evaporator Coils
>
Manufactured Home Furnace Coil
> MFH COIL AC AND OR HP PISTON
MFH COIL AC AND OR HP PISTON
STD EFF 13-14 SEER PQ8
Coil Type
Fin & Tube
Cased/Uncased
Uncased
Positioning
Vertical
Refrigerant
R-410A
Use On
DGA(A,X) or EB, EU furnaces
Nom. Capacity (Tons)
1.5-3
Fits Furnace Width (in.)
19.625
Width (in.)
18
Metering Device
Piston
Warranty
Standard and extended warranty available
Depth (in.)
19.5
Liquid Line Connection (in.)
3/8
Shipping Wt (lbs)
32
Height (in.)
17
Suction Line Connection (in.)
3/4
Test Listing
UL US and Canada
NOTE
Use on DGA(A,X) or EB, EU furnaces
Certification
AHRI
Item #:
CMH18/36PM1M
Manufactured Housing Coils
- Rifled copper tubing, enhanced aluminum fins
- Immersion-tested at 500psi, then nitrogen-pressurized and sealed
- Left-hand refrigerant and plumbing connections
- Externally mounted flowrater body with Schrader valve
- Heavy duty plastic drain pans on all models
- AHRI certifiable with certain brands of A/C and heat pump systems
- UL listed for use with R-22 and R-410A when proper metering device is used
Manufactured Home Furnace Coil
Coil Type
Fin & Tube
Cased/Uncased
Uncased
Positioning
Vertical
Refrigerant
R-410A
Use On
DGA(A,X) or EB, EU furnaces
Nom. Capacity (Tons)
1.5-3
Fits Furnace Width (in.)
19.625
Width (in.)
18
Metering Device
Piston
Warranty
Standard and extended warranty available
Depth (in.)
19.5
Liquid Line Connection (in.)
3/8
Shipping Wt (lbs)
32
Height (in.)
17
Suction Line Connection (in.)
3/4
Test Listing
UL US and Canada
NOTE
Use on DGA(A,X) or EB, EU furnaces
Certification
AHRI
